SAT 04-JUN-2005 (155) - 20
Good Day
DATE: 04-Jun-2005 START TIME: 20:32 STOP TIME: 21:10 POSITION: 20° 48.74' N 157° 10.84' W
Quality Checking |
Engineering Info |
Forth Log
Table of Quality Checking Information
FILE: Complete
PROCESSING: Good Day
CONFIGURATION: mby23001
RAW SCANS W/ PIXELS REMOVED: VR = 64; Pixels = [436 435 434];
VR = 53; Pixels = [846 845 844];
VR = 8; Pixels = [319 318 317];
VR = 34; Pixels = [724 725 726 838 839 840];
VR = 35; Pixels = [939 938 937];
VR = 31; Pixels = [959 958 957];
VR = 33; Pixels = [727 728 729 951 952 953];
VR = 30; Pixels = [955 956 957 975 976 977];
VR = 32; Pixels = [864 865 866 1012 1013 1014];
VR = 20; Pixels = [595 594 593 592 591 590];
VR = 21; Pixels = [605 604 603];
VR = 17; Pixels = [969 968 967];
VR = 18; Pixels = [842 843 844 876 877 878];
VR = 19; Pixels = [538 539 540 629 630 631 787 788 789 841 842 843 935 936 937];
VR = 46; Pixels = [590 591 592 622 623 624];
VR = 44; Pixels = [731 730 729];
VR = 41; Pixels = [812 811 810];
VR = 43; Pixels = [860 859 858];
VR = 47; Pixels = [892 891 890];
VR = 42; Pixels = [943 942 941];
VR = 4; Pixels = [549 548 547];
RAW SCANS W/ PIXELS FILLED: VR = 29; Pixels = [821];
Table of Engineering Information
| LITE | DARK |
| Int Bin Maximum | Int Bin Maximum | MUX No. No.
MOBY | Time Factor Counts | Time Factor Counts | Pos Lite Dark
File Source | (B/R) (B/R) (B/R) | (B/R) (B/R) (B/R) |
-------------------------------------------------------------------------------------------------------------
05060420 LuTop | 40.000/40.000 6/384 34212/22522 | 40.000/40.000 6/384 1180/6378 | 9 5 2
05060420 LuMid | 64.000/64.000 4/384 32783/18276 | 64.000/64.000 4/384 1193/9656 | 5 5 2
05060420 LuBot | 64.000/64.000 4/384 24290/13532 | 64.000/64.000 4/384 1205/9844 | 2 5 2
05060420 EdTop | 0.600/0.600 32/64 28154/23006 | 0.600/0.600 32/64 1001/1033 | 10 5 2
05060420 EdMid | 2.500/2.500 8/64 18749/16351 | 2.500/2.500 8/64 989/1069 | 7 5 2
05060420 EdBot | 2.000/2.000 12/384 17813/18226 | 2.000/2.000 12/384 994/1340 | 3 5 2
05060420 EsSfc | 0.750/0.750 16/16 29189/21319 | 0.750/0.750 16/16 986/1012 | 8 3 2
05060420 Blue LED| 1.000/1.000 64/384 30036/1842 | 1.000/1.000 64/384 1051/1232 | 12 3 2
05060420 Blue LED| 1.000/1.000 64/384 30083/1840 | 1.000/1.000 64/384 1044/1212 | 12 3 2
05060420 Red LED | 1.000/1.000 384/64 15147/31316 | 1.000/1.000 384/64 1418/1052 | 13 3 2
05060420 Red LED | 1.000/1.000 384/64 15293/30870 | 1.000/1.000 384/64 1462/1053 | 13 3 2
05060420 Lamp | 1.000/1.000 64/16 28661/40606 | 1.000/1.000 64/16 1048/1025 | 15 3 2
| (sec) (pixel) (AD U) | (sec) (pixel) (ADU) |
FORTH LOG FILE
No FORTH LOG file appears to exist for this MOBY file
QCHK FILE
% 05060420.mob Quality Check ASCII file: created on 06-Jun-2005 by MKQCHK_
OPTION2: VRpixRMD = 64; ERpixRMD = [436 435 434]; OPTDATESTR ='06-Jun-2005 11:52:35';
OPTION2: VRpixRMD = 53; ERpixRMD = [846 845 844]; OPTDATESTR ='06-Jun-2005 11:52:51';
OPTION2: VRpixRMD = 8; ERpixRMD = [319 318 317]; OPTDATESTR ='06-Jun-2005 11:53:07';
OPTION5: MOBYFNMS = '05060420.mob'; QCHKFLAG = 1; QCHKWHAT = 1; QCHKWHO = 1; OPTDATESTR ='06-Jun-2005 11:54:21';
OPTION11: MOBYFNMS = '05060420.mob'; QCHKFLAG = 0; QCHKWHAT = 1; QCHKWHO = 1; OPTDATESTR ='06-Jun-2005 11:54:21';
OPTION2: VRpixRMD = 34; ERpixRMD = [724 725 726 838 839 840]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 35; ERpixRMD = [939 938 937]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 31; ERpixRMD = [959 958 957]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 33; ERpixRMD = [727 728 729 951 952 953]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 30; ERpixRMD = [955 956 957 975 976 977]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 32; ERpixRMD = [864 865 866 1012 1013 1014]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 20; ERpixRMD = [595 594 593 592 591 590]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 21; ERpixRMD = [605 604 603]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 17; ERpixRMD = [969 968 967]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 18; ERpixRMD = [842 843 844 876 877 878]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 19; ERpixRMD = [538 539 540 629 630 631 787 788 789 841 842 843 935 936 937]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 46; ERpixRMD = [590 591 592 622 623 624]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 44; ERpixRMD = [731 730 729]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 41; ERpixRMD = [812 811 810]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 43; ERpixRMD = [860 859 858]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 47; ERpixRMD = [892 891 890]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 42; ERpixRMD = [943 942 941]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION2: VRpixRMD = 4; ERpixRMD = [549 548 547]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
OPTION14: VRpixFILL = 29; ERpixFILL = [821]; OPTDATESTR ='11-Oct-2016 21:21:55'; % RSG384FIX_
% RSG384FIX_ run on 11-Oct-2016 21:21:55
OPTION13: MOBYFNMS = '05060420.mob'; CONfile = 'mby23001'; OPTDATESTR ='10-Nov-2017 16:33:38';
