SUN 17-JUL-2005 (198) - 22
Bad Day
DATE: 17-Jul-2005 START TIME: 22:32 STOP TIME: 23:07 POSITION: 20° 49.3' N 157° 11' W
Quality Checking |
Engineering Info |
Forth Log
Table of Quality Checking Information
FILE: Complete
PROCESSING: Bad
CONFIGURATION: mby23001
RAW SCANS W/ PIXELS REMOVED: VR = 12; Pixels = [822 821 820];
VR = 36; Pixels = [794 793 792 791];
VR = 33; Pixels = [922 921 920];
VR = 37; Pixels = [862 943 944 945 954 955];
VR = 34; Pixels = [974 973 972];
VR = 20; Pixels = [573 572 571];
VR = 18; Pixels = [611 610 609];
VR = 19; Pixels = [651 652 653 818 819 820];
VR = 48; Pixels = [623 622 621];
VR = 44; Pixels = [816 815 814];
VR = 45; Pixels = [931 932 933 962 963 964];
VR = 57; Pixels = [599 598 597];
VR = 2; Pixels = [949 948 947];
RAW SCANS W/ PIXELS FILLED: VR = 33; Pixels = [718];
VR = 30; Pixels = [729 730];
VR = 24; Pixels = [656];
Table of Engineering Information
| LITE | DARK |
| Int Bin Maximum | Int Bin Maximum | MUX No. No.
MOBY | Time Factor Counts | Time Factor Counts | Pos Lite Dark
File Source | (B/R) (B/R) (B/R) | (B/R) (B/R) (B/R) |
-------------------------------------------------------------------------------------------------------------
05071722 LuTop | 56.000/56.000 4/384 39795/30946 | 56.000/56.000 4/384 1203/9576 | 9 6 2
05071722 LuMid | 56.000/56.000 4/384 34869/16298 | 56.000/56.000 4/384 1214/9784 | 5 6 2
05071722 LuBot | 56.000/56.000 4/384 12047/10794 | 56.000/56.000 4/384 1211/9752 | 2 6 2
05071722 EsSfc | 0.750/0.750 16/16 39231/28630 | 0.750/0.750 16/16 985/1015 | 8 3 2
05071722 Blue LED| 1.000/1.000 64/384 29559/1856 | 1.000/1.000 64/384 1069/1224 | 12 3 2
05071722 Blue LED| 1.000/1.000 64/384 29778/1848 | 1.000/1.000 64/384 1068/1228 | 12 3 2
05071722 Red LED | 1.000/1.000 384/64 15279/30836 | 1.000/1.000 384/64 1525/1052 | 13 3 2
05071722 Red LED | 1.000/1.000 384/64 15212/30595 | 1.000/1.000 384/64 1517/1068 | 13 3 2
05071722 Lamp | 1.000/1.000 64/16 28688/40769 | 1.000/1.000 64/16 1059/1022 | 15 3 2
| (sec) (pixel) (AD U) | (sec) (pixel) (ADU) |
FORTH LOG FILE
No FORTH LOG file appears to exist for this MOBY file
QCHK FILE
% 05071722.mob Quality Check ASCII file: created on 13-Jan-2006 by MKQCHK_
OPTION2: VRpixRMD = 12; ERpixRMD = [822 821 820]; OPTDATESTR ='13-Jan-2006 22:26:09';
OPTION5: MOBYFNMS = '05071722.mob'; QCHKFLAG = 0; QCHKWHAT = 1; QCHKWHO = 2; QCHKCODE = 4209; OPTDATESTR ='13-Jan-2006 22:27:37';
OPTION2: VRpixRMD = 36; ERpixRMD = [794 793 792 791]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 33; ERpixRMD = [922 921 920]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 37; ERpixRMD = [862 943 944 945 954 955]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 34; ERpixRMD = [974 973 972]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 20; ERpixRMD = [573 572 571]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 18; ERpixRMD = [611 610 609]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 19; ERpixRMD = [651 652 653 818 819 820]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 48; ERpixRMD = [623 622 621]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 44; ERpixRMD = [816 815 814]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 45; ERpixRMD = [931 932 933 962 963 964]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 57; ERpixRMD = [599 598 597]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION2: VRpixRMD = 2; ERpixRMD = [949 948 947]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION14: VRpixFILL = 33; ERpixFILL = [718]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION14: VRpixFILL = 30; ERpixFILL = [729 730]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
OPTION14: VRpixFILL = 24; ERpixFILL = [656]; OPTDATESTR ='11-Oct-2016 21:22:22'; % RSG384FIX_
% RSG384FIX_ run on 11-Oct-2016 21:22:22
OPTION13: MOBYFNMS = '05071722.mob'; CONfile = 'mby23001'; OPTDATESTR ='10-Nov-2017 16:41:40';
