TUE 21-JUL-2009 (202) - 22      Questionable Day

DATE: 21-Jul-2009     START TIME: 22:32     STOP TIME: 22:56     POSITION: 20° 48.54' N 157° 11.86' W
Quality Checking | Engineering Info | Forth Log
2009072122_01.png 2009072122_02.png 2009072122_03.png 2009072122_04.png 2009072122_05.png 2009072122_06.png
Table of Quality Checking Information
FILE:                                    Complete

PROCESSING:                              Questionable Day

CONFIGURATION:                           mby24301

RAW SCANS MARKED BAD:                    VR = 11; DscS = 'TOO LOW'; FhdS = '';
                                         VR = 10; DscS = 'TOO LOW'; FhdS = ''
                                         VR = 57; DscS = 'TOO LOW'; FhdS = ''

RAW SCANS W/ PIXELS REMOVED:             VR = 23; Pixels = [581  582  583  841  842  843];
                                         VR = 26; Pixels = [807  808  991  992];
                                         VR = 10; Pixels = [907  906  905];
                                         VR = 37; Pixels = [905  904  903];
                                         VR = 36; Pixels = [864  865  866  867  868  869  870  898  899  900];
                                         VR = 35; Pixels = [843  842  841];
                                         VR = 38; Pixels = [824   825   826   892   893   894   998   999  1000];
                                         VR = 46; Pixels = [558  557  556];
                                         VR = 48; Pixels = [859  858  857];
                                         VR = 51; Pixels = [1005  1004  1003];
                                         VR = 62; Pixels = [635  636  637  737  738  739];

RAW SCANS W/ PIXELS FILLED:              VR = 25; Pixels = [667];
                                         VR = 27; Pixels = [915  916];
                                         VR = 20; Pixels = [914  915  916];
                                         VR = 11; Pixels = [720];
                                         VR = 14; Pixels = [980];
                                         VR = 34; Pixels = [568];
                                         VR = 40; Pixels = [637  638];
Table of Engineering Information
                 |           LITE                      |           DARK                       |
                 |            Int       Bin    Maximum |            Int       Bin     Maximum |     MUX    No.    No.
    MOBY         |           Time    Factor     Counts |           Time    Factor      Counts |     Pos   Lite   Dark
    File  Source |          (B/R)     (B/R)      (B/R) |          (B/R)     (B/R)       (B/R) |
-------------------------------------------------------------------------------------------------------------
09072122 LuTop   |  30.000/30.000   12/384  30593/13015 |  30.000/30.000   12/384    984/2894   |     8      6      2
09072122 LuMid   |  30.000/30.000   12/384  25688/6260  |  30.000/30.000   12/384    990/3031   |     9      6      2
09072122 LuBot   |  30.000/30.000   12/384  29406/5229  |  30.000/30.000   12/384    984/2911   |     1      6      2
09072122 LuMOS   |   5.000/5.000     1/384  18336/17541 |   5.000/5.000     1/384    913/1355   |    11      6      2
09072122 EsSfc   |   0.750/0.750    32/32   25243/20760 |   0.750/0.750    32/32     928/1037   |     5      3      2
09072122 Blue LED|   1.000/1.000    64/384  40781/1930  |   1.000/1.000    64/384    928/1110   |    12      3      2
09072122 Red LED |   1.000/1.000   384/64   18627/48658 |   1.000/1.000   384/64    1015/1043   |    13      3      2
09072122 Lamp    |   1.000/1.000    64/8    45480/43529 |   1.000/1.000    64/8      929/1032   |    15      3      2
                 |        (sec)   (pixel)      (AD U) |        (sec)   (pixel)        (ADU) |
FORTH LOG FILE

The battery selcted for 2009072122.mby is #1 at 13.431 volts

21/07/2009 16:20:07 USER LOGGED OFF
21/07/2009 16:24:01 MODEM STOPPED
21/07/2009 16:24:02 Temperature (deg):  TT7 = 31 (1803) Case = 26 (2013)  % Humidity: 4 (758)
21/07/2009 16:24:02 SHUTTING DOWN SYSTEM
21/07/2009 16:24:03 SHUTDOWN:  MOSOFF
21/07/2009 16:24:07 SHUTDOWN:  CHRGBATT
21/07/2009 16:24:22 CHRGBATT:  CHARGING UPPER BATTERY
21/07/2009 16:24:23 CHRGBATT:  UPPER BATTERY = 12.155 VOLTS
21/07/2009 16:24:24 SHUTDOWN:  TT5OFF
21/07/2009 16:24:25 SHUTDOWN:  GPSOFF
21/07/2009 16:24:25 SHUTDOWN:  APWR-OFF
21/07/2009 16:24:26 SHUTDOWN:  MODEMOFF
21/07/2009 16:24:27 END SHUTDOWN
21/07/2009 19:00:06 Temperature (deg):  TT7 = 25 (2031) Case = 25 (2034)  % Humidity: 5 (771)
21/07/2009 19:00:18 GPS STARTED
21/07/2009 19:00:19 WAKEGPS:  UPPER BATTERY = 13.407 VOLTS
21/07/2009 19:01:05 GPS at 19:01:35, DelTime 29.63, Lat 20:48.8356' N, Lon 157:12.0793' W
21/07/2009 19:01:06 $GPGGA,190135,2048.8356,N,15712.0793,W,1,08,1.0,11.0,M,04.1,M,00,0000*68
21/07/2009 19:01:07 GPS STOPPED
21/07/2009 19:01:08 Temperature (deg):  TT7 = 26 (2022) Case = 25 (2033)  % Humidity: 5 (772)
21/07/2009 19:01:08 SHUTTING DOWN SYSTEM
21/07/2009 19:01:09 SHUTDOWN:  MOSOFF
21/07/2009 19:01:13 SHUTDOWN:  CHRGBATT
21/07/2009 19:01:39 LOWER BATTERY VOLTAGES (1 to 4) =  13.016 N/A 13.114 13.101
21/07/2009 19:01:40 CHRGBATT:  CHARGING LOWER BATTERY #1 = 13.016 VOLTS
21/07/2009 19:01:45 CHRGBATT:  UPPER BATTERY = 13.339 VOLTS
21/07/2009 19:01:46 SHUTDOWN:  TT5OFF
21/07/2009 19:01:47 SHUTDOWN:  GPSOFF
21/07/2009 19:01:48 SHUTDOWN:  APWR-OFF
21/07/2009 19:01:48 SHUTDOWN:  MODEMOFF
21/07/2009 19:01:49 END SHUTDOWN
21/07/2009 20:15:06 Temperature (deg):  TT7 = 25 (2045) Case = 25 (2051)  % Humidity: 5 (770)
21/07/2009 20:15:07 MOBY STARTED
21/07/2009 20:15:33 LOWER BATTERY VOLTAGES (1 to 4) =  13.431 N/A 13.077 13.016
21/07/2009 20:15:34 MOBY:  UPPER BATTERY = 13.089 VOLTS
21/07/2009 20:15:51 SELECTBATT:  LOWER BATTERY SELECTED # 1 = 13.431 VOLTS
21/07/2009 21:00:00 MOBY STOPPED
21/07/2009 21:00:01 Temperature (deg):  TT7 = 34 (1703) Case = 26 (2026)  % Humidity: 4 (753)
21/07/2009 21:00:02 SHUTTING DOWN SYSTEM
21/07/2009 21:00:03 SHUTDOWN:  MOSOFF
21/07/2009 21:00:04 SHUTDOWN:  CHRGBATT
21/07/2009 21:00:20 LOWER BATTERY VOLTAGES (1 to 4) =  12.735 N/A 13.101 12.967
21/07/2009 21:00:21 CHRGBATT:  CHARGING LOWER BATTERY #1 = 12.735 VOLTS
21/07/2009 21:00:26 CHRGBATT:  UPPER BATTERY = 12.918 VOLTS
21/07/2009 21:00:27 SHUTDOWN:  TT5OFF
21/07/2009 21:00:28 SHUTDOWN:  GPSOFF
21/07/2009 21:00:29 SHUTDOWN:  APWR-OFF
21/07/2009 21:00:30 SHUTDOWN:  MODEMOFF
21/07/2009 21:00:31 END SHUTDOWN
21/07/2009 22:00:06 Temperature (deg):  TT7 = 26 (2014) Case = 26 (2029)  % Humidity: 4 (769)
21/07/2009 22:00:07 SHUTTING DOWN SYSTEM
21/07/2009 22:00:07 SHUTDOWN:  MOSOFF
21/07/2009 22:00:11 SHUTDOWN:  CHRGBATT
21/07/2009 22:00:27 LOWER BATTERY VOLTAGES (1 to 4) =  13.639 N/A 13.077 13.004
21/07/2009 22:00:28 CHRGBATT:  CHARGING LOWER BATTERY #4 = 13.004 VOLTS
21/07/2009 22:00:33 CHRGBATT:  UPPER BATTERY = 12.937 VOLTS
21/07/2009 22:00:34 SHUTDOWN:  TT5OFF
21/07/2009 22:00:35 SHUTDOWN:  GPSOFF
21/07/2009 22:00:36 SHUTDOWN:  APWR-OFF
21/07/2009 22:00:36 SHUTDOWN:  MODEMOFF
21/07/2009 22:00:37 END SHUTDOWN
21/07/2009 22:15:06 Temperature (deg):  TT7 = 26 (2020) Case = 25 (2032)  % Humidity: 4 (769)
21/07/2009 22:15:07 MOBY STARTED
21/07/2009 22:15:33 LOWER BATTERY VOLTAGES (1 to 4) =  13.431 N/A 13.065 13.382
21/07/2009 22:15:34 MOBY:  UPPER BATTERY = 12.979 VOLTS
21/07/2009 22:15:50 SELECTBATT:  LOWER BATTERY SELECTED # 1 = 13.431 VOLTS
21/07/2009 22:56:27 MOBY STOPPED
21/07/2009 22:56:28 Temperature (deg):  TT7 = 34 (1702) Case = 26 (2020)  % Humidity: 4 (753)
21/07/2009 22:56:29 SHUTTING DOWN SYSTEM
21/07/2009 22:56:30 SHUTDOWN:  MOSOFF
21/07/2009 22:56:31 SHUTDOWN:  CHRGBATT
21/07/2009 22:56:47 LOWER BATTERY VOLTAGES (1 to 4) =  12.747 N/A 13.089 13.162
21/07/2009 22:56:48 CHRGBATT:  CHARGING LOWER BATTERY #1 = 12.747 VOLTS
21/07/2009 22:56:53 CHRGBATT:  UPPER BATTERY = 12.827 VOLTS
21/07/2009 22:56:54 SHUTDOWN:  TT5OFF
21/07/2009 22:56:55 SHUTDOWN:  GPSOFF
21/07/2009 22:56:56 SHUTDOWN:  APWR-OFF
21/07/2009 22:56:57 SHUTDOWN:  MODEMOFF
21/07/2009 22:56:58 END SHUTDOWN
21/07/2009 23:45:06 Temperature (deg):  TT7 = 27 (1984) Case = 26 (2017)  % Humidity: 4 (766)
21/07/2009 23:45:07 MOBY STARTED
21/07/2009 23:45:33 LOWER BATTERY VOLTAGES (1 to 4) =  13.639 N/A 13.077 13.053
21/07/2009 23:45:34 MOBY:  UPPER BATTERY = 12.912 VOLTS
21/07/2009 23:45:51 SELECTBATT:  LOWER BATTERY SELECTED # 1 = 13.553 VOLTS
22/07/2009 00:30:01 MOBY STOPPED
22/07/2009 00:30:02 Temperature (deg):  TT7 = 35 (1660) Case = 26 (1991)  % Humidity: 4 (752)
22/07/2009 00:30:03 SHUTTING DOWN SYSTEM
22/07/2009 00:30:04 SHUTDOWN:  MOSOFF
22/07/2009 00:30:06 SHUTDOWN:  CHRGBATT
22/07/2009 00:30:21 LOWER BATTERY VOLTAGES (1 to 4) =  12.735 N/A 13.089 13.028
22/07/2009 00:30:22 CHRGBATT:  CHARGING LOWER BATTERY #1 = 12.735 VOLTS
22/07/2009 00:30:27 CHRGBATT:  UPPER BATTERY = 12.796 VOLTS
22/07/2009 00:30:28 SHUTDOWN:  TT5OFF
22/07/2009 00:30:29 SHUTDOWN:  GPSOFF
22/07/2009 00:30:30 SHUTDOWN:  APWR-OFF
22/07/2009 00:30:31 SHUTDOWN:  MODEMOFF
22/07/2009 00:30:32 END SHUTDOWN
22/07/2009 01:00:06 Temperature (deg):  TT7 = 29 (1905) Case = 27 (1983)  % Humidity: 4 (764)
22/07/2009 01:00:07 SHUTTING DOWN SYSTEM
22/07/2009 01:00:07 SHUTDOWN:  MOSOFF
22/07/2009 01:00:11 SHUTDOWN:  CHRGBATT
22/07/2009 01:00:27 LOWER BATTERY VOLTAGES (1 to 4) =  13.541 N/A 13.077 13.053
22/07/2009 01:00:28 CHRGBATT:  CHARGING LOWER BATTERY #4 = 13.053 VOLTS
22/07/2009 01:00:33 CHRGBATT:  UPPER BATTERY = 12.833 VOLTS
22/07/2009 01:00:34 SHUTDOWN:  TT5OFF
22/07/2009 01:00:35 SHUTDOWN:  GPSOFF
22/07/2009 01:00:36 SHUTDOWN:  APWR-OFF
22/07/2009 01:00:36 SHUTDOWN:  MODEMOFF
22/07/2009 01:00:37 END SHUTDOWN
22/07/2009 03:00:06 Temperature (deg):  TT7 = 26 (2017) Case = 26 (2013)  % Humidity: 5 (770)
22/07/2009 03:00:07 GPS STARTED
22/07/2009 03:00:07 WAKEGPS:  UPPER BATTERY = 12.851 VOLTS
22/07/2009 03:00:23 GPS at 3:00:53, DelTime 29.66, Lat 20:48.5108' N, Lon 157:11.7931' W
22/07/2009 03:00:24 $GPGGA,030053,2048.5108,N,15711.7931,W,1,00,1.8,16.5,M,04.1,M,00,0000*66
22/07/2009 03:00:25 GPS STOPPED
22/07/2009 03:00:26 Temperature (deg):  TT7 = 26 (2012) Case = 26 (2013)  % Humidity: 5 (770)
22/07/2009 03:00:26 SHUTTING DOWN SYSTEM
22/07/2009 03:00:27 SHUTDOWN:  MOSOFF
22/07/2009 03:00:31 SHUTDOWN:  CHRGBATT
22/07/2009 03:00:47 LOWER BATTERY VOLTAGES (1 to 4) =  13.101 N/A 13.028 13.223
22/07/2009 03:00:48 CHRGBATT:  CHARGING LOWER BATTERY #3 = 13.028 VOLTS
22/07/2009 03:00:53 CHRGBATT:  UPPER BATTERY = 12.839 VOLTS
22/07/2009 03:00:54 SHUTDOWN:  TT5OFF
22/07/2009 03:00:55 SHUTDOWN:  GPSOFF
22/07/2009 03:00:56 SHUTDOWN:  APWR-OFF
22/07/2009 03:00:56 SHUTDOWN:  MODEMOFF
22/07/2009 03:00:57 END SHUTDOWN
22/07/2009 04:00:06 Temperature (deg):  TT7 = 25 (2030) Case = 26 (2024)  % Humidity: 5 (771)
22/07/2009 04:00:07 MODEM STARTED
22/07/2009 04:00:08 WAKEMODEM:  UPPER BATTERY = 12.851 VOLTS
22/07/2009 04:02:17 USER LOGGED ON
QCHK FILE
% 09072122.mob Quality Check ASCII file: created on 22-Jul-2009 by   MKQCHK_
OPTION1: VRmarkBAD = 11; DSCSmarkBAD = 'TOO LOW'; FHDSmarkBAD = '';  OPTDATESTR ='22-Jul-2009 16:46:48';
OPTION1: VRmarkBAD = 10; DSCSmarkBAD = 'TOO LOW'; FHDSmarkBAD = '';  OPTDATESTR ='22-Jul-2009 16:46:48';
OPTION1: VRmarkBAD = 57; DSCSmarkBAD = 'TOO LOW'; FHDSmarkBAD = '';  OPTDATESTR ='22-Jul-2009 16:47:03';
OPTION5: MOBYFNMS = '09072122.mob'; QCHKFLAG = 2; QCHKWHAT = 1; QCHKWHO = 2; QCHKCODE = 80;  OPTDATESTR ='22-Jul-2009 16:48:51';
OPTION2: VRpixRMD = 23; ERpixRMD = [581  582  583  841  842  843]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 26; ERpixRMD = [807  808  991  992]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 10; ERpixRMD = [907  906  905]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 37; ERpixRMD = [905  904  903]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 36; ERpixRMD = [864  865  866  867  868  869  870  898  899  900]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 35; ERpixRMD = [843  842  841]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 38; ERpixRMD = [824   825   826   892   893   894   998   999  1000]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 46; ERpixRMD = [558  557  556]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 48; ERpixRMD = [859  858  857]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 51; ERpixRMD = [1005  1004  1003]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION2: VRpixRMD = 62; ERpixRMD = [635  636  637  737  738  739]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION14: VRpixFILL = 25; ERpixFILL = [667]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION14: VRpixFILL = 27; ERpixFILL = [915  916]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION14: VRpixFILL = 20; ERpixFILL = [914  915  916]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION14: VRpixFILL = 11; ERpixFILL = [720]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION14: VRpixFILL = 14; ERpixFILL = [980]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION14: VRpixFILL = 34; ERpixFILL = [568]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
OPTION14: VRpixFILL = 40; ERpixFILL = [637  638]; OPTDATESTR ='11-Oct-2016 21:25:12'; % RSG384FIX_
% RSG384FIX_ run on 11-Oct-2016 21:25:12
OPTION13: MOBYFNMS = '09072122.mob'; CONfile = 'mby24301';  OPTDATESTR ='12-Nov-2017 13:16:16';

Stephanie Flora - Moss Landing Marine Laboratories
