MOBY253 Information/Configuration Page
Deployment Events
WED 28-AUG-2013 (240) - 00 hour file has a major battery problem. The battery volts dropped to below 9.5 volts
for 3-5 scans. All the data looked like crap. Ken and Mark think one of the 4 marine battery cells dropped out. The array temperatures were above 20 degress C.
WED 11-SEP-2013 (254) - Marco uploaded new MOBYACQ.** files to change the bin factors and integration times on MOBY so
the data is no saturating.
THU 12-SEP-2013 (255) - We found that the M253 data (mainly LuTop, Bot and Es) were saturated for the 22 and 23 hour
files for waves around 500 nm. Fixing the data is not really possible at this time so most of the 22 and 23
hour data before the config change will be marked bad.
FRI 11-OCT-2013 (284) - 23 hour file has a major battery problem. The battery volts dropped to below 7 volts two times
during data collection. Much of the data looks like crap. Is is possible that in this case two of the 4 marine battery cells dropped out. The array temperatures were well above 100 degress C, two times during data collection.
MOBYs physical Configuration
| Sensor | MUX Position | Depth (m) |
|---|
| Es SFC |
5 |
N/A |
| Ed TOP |
7 |
1.452 |
| Lu TOP |
8 |
1.576 |
| Ed MID |
2 |
5.382 |
| Lu MID |
9 |
5.506 |
| Ed BOT |
10 |
9.282 |
| Lu BOT |
1 |
9.406 |
| Eu MOS |
6 |
N/A |
| LuMOS |
11 |
11.417 |
| BLUE LED |
12 |
N/A |
| RED LED |
13 |
N/A |
| LAMP |
15 |
N/A |
MOS2 Vaux Analog Data Types
| Name | Code | Conversion |
|---|
| Unknown |
-1 |
X; |
| None |
0 |
X; |
| Water Temperature (deg C) |
10 |
(2.5551e-015).*X^4+(-1.2120e-010).*X^3+(2.0394e-006)*X^2 + (-2.0680e-002)*X + 1.1270e+002; |
| Blue array temp (deg C) |
11 |
(3.0518E-2)*X; |
| Red array temp (deg C) |
12 |
(3.0518E-2)*X; |
| Calib src block temp (deg C) |
13 |
(-4.6789E-16)*X^4 - (1.7279E-11)*X^3 + (7.2224E-07)*X^2 - (1.3381E-02)*X + 9.7741E+01; |
| Depth Sensor temp (deg C) |
14 |
(-4.6789E-16)*X^4 - (1.7279E-11)*X^3 + (7.2224E-07)*X^2 - (1.3381E-02)*X + 9.7741E+01; |
| Blue CCD head temp (deg C) |
15 |
(-4.6789E-16)*X^4 - (1.7279E-11)*X^3 + (7.2224E-07)*X^2 - (1.3381E-02)*X + 9.7741E+01; |
| Red CCD head temp (deg C) |
16 |
(-4.6789E-16)*X^4 - (1.7279E-11)*X^3 + (7.2224E-07)*X^2 - (1.3381E-02)*X + 9.7741E+01; |
| TT7 board temp (deg C) |
17 |
(-1.1978E-13)*X^4 - (1.1059E-09)*X^3 + (1.1556E-05)*X^2 - (5.3524E-02)*X + 9.7741E+01; |
| TT7 case temp (deg C) |
18 |
(-1.1978E-13)*X^4 - (1.1059E-09)*X^3 + (1.1556E-05)*X^2 - (5.3524E-02)*X + 9.7741E+01; |
| Depth (meters) |
20 |
(1.3423E-09)*X^2 + (1.2839E-02)*X + 2.2724E-02; |
| X Tilt (degrees) |
21 |
(-2.2218E-13)*X^3 + (1.5007E-10)*X^2 + (3.0805E-03)*X + 6.1564E-03; |
| Y Tilt (degrees) |
22 |
(-8.2511E-14)*X^3 + (8.6841E-10)*X^2 + (3.0540E-03)*X - 3.3977E-02; |
| Inclination |
2122 |
X; |
| Blue cal diode mon (volts) |
23 |
(3.0518E-4)*X; |
| Red cal diode mon (volts) |
24 |
(3.0518E-4)*X; |
| Blue heat mon (volts) |
25 |
(3.0518E-4)*X; |
| Red heat mon (volts) |
26 |
(3.0518E-4)*X; |
| Coolant flow (liters/min) |
27 |
(6.1035E-5)*X; |
| System current (amps) |
28 |
(3.05E-3)*X - 40; |
| TT7 Mains (volts) |
29 |
(6.105E-3)*X; |
| TT7 case humidity (%RH) |
30 |
(X*0.02906-19)/(1.054-.00216*T); |
MOS2 Faux Analog Data Types
| Name | Code | Conversion |
|---|
| TT7 upper bat (volts) |
100 |
6.104E-03*X |
| TT7 board temp (deg C) |
101 |
-1.1978E-13*X^4 -1.1059E-09*X^3 +1.1556E-05*X^2 -5.3524E-02*X +9.7741E+01; |
| TT7 case temp (deg C) |
102 |
-1.1978E-13*X^4 -1.1059E-09*X^3 +1.1556E-05*X^2 -5.3524E-02*X +9.7741E+01; |
| TT7 case humidity (%RH) |
103 |
(X*0.02906-19)/(1.054-.00216*T); |
| Solar panel #1 current (Amps) |
104 |
3.052E-4*X; |
| Solar panel #2 current (Amps) |
105 |
3.052E-4*X; |
| Solar panel #3 current (Amps) |
106 |
3.052E-4*X; |
| Solar panel #4 current (Amps) |
107 |
3.052E-4*X; |
| Upper bat. charge current (Amps) |
108 |
6.104-4*X; |
| Upper arm collector depth (Meters) |
109 |
(0.0003*X - 0.9272)-0.985; |
| Upper bat. drain current (Amps) |
110 |
6.104-4*X; |
| N/A |
111 |
(NaN); |
| TT5 mains power (Volts) |
112 |
6.104E-03*X; |
| Lower bat. charge current (Amps) |
113 |
3.662E-3*X; |
| MOS current (Amps) |
114 |
3.662E-3*X; |
| MOS voltage (Volts) |
115 |
6.104E-03*X; |
| Lower Battery #1 (Volts) |
116 |
1.221E-2*X; |
| Lower Battery #2 (Volts) |
117 |
1.221E-2*X; |
| Lower Battery #3 (Volts) |
118 |
1.221E-2*X; |
| Lower Battery #4 (Volts) |
119 |
1.221E-2*X; |
System Response Information
File: 253_RSP.MLD
DscS 14: MOBY253 Nominal Integration Time (sec)
DscS 15: MOBY253 Calibrated Integration Time (sec)
DscS 16: MOBY253 Nominal CCD Bin Factor (pix)
DscS 17: MOBY253 Calibrated CCD Bin Factor (pix)
Xdat:
NomInt, CalInt, NomBin, CalBin
0.050000, 0.066607, 1.000, 1.000
0.100000, 0.115757, 2.000, 2.000
0.200000, 0.213580, 3.000, 3.000
0.250000, 0.262470, 4.000, 4.000
0.400000, 0.409303, 6.000, 6.000
0.500000, 0.507344, 8.000, 8.000
0.800000, 0.802046, 12.000, 12.000
1.000000, 0.998863, 16.000, 16.000
2.000000, 1.985070, 24.000, 24.000
2.500000, 2.478875, 32.000, 32.000
3.000000, 2.972933, 48.000, 48.000
4.000000, 3.961566, 64.000, 64.000
5.000000, 4.950710, 96.000, 96.000
6.000000, 5.940270, 128.000, 128.000
8.000000, 7.920518, 192.000, 192.000
10.000000, 9.902205, 384.000, 384.000
12.000000, 11.885306, ,
16.000000, 15.855642, ,
20.000000, 19.831234, ,
24.000000, 23.811710, ,
25.000000, 24.807545, ,
30.000000, 29.790697, ,
32.000000, 31.785700, ,
40.000000, 39.774513, ,
48.000000, 47.775410, ,
50.000000, 49.777241, ,
60.000000, 59.794361, ,
64.000000, 63.804386, ,
96.000000, 95.923920, ,
100.000000, 99.941498, ,
128.000000,128.063400, ,
256.000000,256.049988, ,
--------------------------------------------------------------------------------------------------
MOBY253: Table of Engineering Information
--------------------------------------------------------------------------------------------------
HOUR: 0 | | LITE DARK |
| Int Bin | Maximum Maximum | No. No.
| Time Factor | Counts Counts | Lite Dark
Date Source | (B/R) (B/R) | (B/R) (B/R) |
--------------------------------------------------------------------------------------------------
2014007 LuTop | 60.00/60.00 6/384 | 41037/61936 1152/7364 | 5 2
2013255 | 30.00/60.00 16/384 | 41037/61936 1152/7364 | 5 2
2014007 LuMid | 60.00/60.00 6/384 | 34980/11305 1163/8039 | 5 2
2013255 | 30.00/60.00 16/384 | 34980/11305 1163/8039 | 5 2
2014007 LuBot | 60.00/60.00 6/384 | 37047/10518 1183/7336 | 5 2
2013255 | 30.00/60.00 16/384 | 37047/10518 1183/7336 | 5 2
2014007 LuMOS | 8.00/8.00 1/384 | 47654/33811 916/2138 | 5 2
2014007 EdTop | 1.00/1.00 24/64 | 10676/12303 925/1056 | 5 2
2014007 EdMid | 1.50/1.50 24/64 | 30157/9456 933/1063 | 5 2
2014007 EdBot | 2.00/2.00 24/384 | 25158/10456 956/1749 | 5 2
2014007 EsSfc | 1.13/1.13 16/16 | 41171/29528 1222/1571 | 3 2
2014007 Blue LED | 1.00/1.00 64/384 | 38913/2075 975/1165 | 3 2
2014007 Red LED | 1.00/1.00 384/64 | 15990/24062 1188/1238 | 3 2
2014007 Lamp | 1.00/1.00 64/16 | 44991/58163 960/1053 | 3 2
--------------------------------------------------------------------------------------------------
HOUR: 22 | | LITE DARK |
| Int Bin | Maximum Maximum | No. No.
| Time Factor | Counts Counts | Lite Dark
Date Source | (B/R) (B/R) | (B/R) (B/R) |
--------------------------------------------------------------------------------------------------
2014006 LuTop | 60.00/60.00 6/384 | 44030/38521 1096/6868 | 5 2
2013254 | 30.00/60.00 16/384 | 44030/38521 1096/6868 | 5 2
2014006 LuMid | 60.00/60.00 6/384 | 40352/11936 1104/7567 | 5 2
2013254 | 30.00/60.00 16/384 | 40352/11936 1104/7567 | 5 2
2014006 LuBot | 60.00/60.00 6/384 | 44171/10918 1102/6877 | 5 2
2013254 | 30.00/60.00 16/384 | 44171/10918 1102/6877 | 5 2
2014006 LuMOS | 8.00/8.00 1/384 | 49566/40377 915/1957 | 5 2
2014006 EdTop | 1.00/1.00 24/64 | 12995/17900 928/1054 | 5 2
2014006 EdMid | 1.50/1.50 24/64 | 43495/15062 934/1061 | 5 2
2014006 EdBot | 2.00/2.00 24/384 | 30493/15582 955/1261 | 5 2
2014006 EsSfc | 1.13/1.13 16/16 | 45096/32714 932/1041 | 3 2
2014006 Blue LED | 1.00/1.00 64/384 | 39158/2090 952/1164 | 3 2
2014006 Red LED | 1.00/1.00 384/64 | 16126/24253 1162/1085 | 3 2
2014006 Lamp | 1.00/1.00 64/16 | 44829/57967 974/1052 | 3 2
--------------------------------------------------------------------------------------------------
HOUR: 23 | | LITE DARK |
| Int Bin | Maximum Maximum | No. No.
| Time Factor | Counts Counts | Lite Dark
Date Source | (B/R) (B/R) | (B/R) (B/R) |
--------------------------------------------------------------------------------------------------
2014006 LuTop | 60.00/60.00 6/384 | 44809/51625 2999/7242 | 5 2
2013254 | 30.00/60.00 16/384 | 44809/51625 2999/7242 | 5 2
2014006 LuMid | 60.00/60.00 6/384 | 39534/12238 1150/7911 | 5 2
2013254 | 30.00/60.00 16/384 | 39534/12238 1150/7911 | 5 2
2014006 LuBot | 60.00/60.00 6/384 | 44918/11036 1134/7649 | 5 2
2013254 | 30.00/60.00 16/384 | 44918/11036 1134/7649 | 5 2
2014006 LuMOS | 8.00/8.00 1/384 | 50874/53301 913/2026 | 5 2
2014007 EdTop | 1.00/1.00 24/64 | 12418/21832 6023/6192 | 5 2
2014007 EdMid | 1.50/1.50 24/64 | 32095/10749 959/1134 | 5 2
2014007 EdBot | 2.00/2.00 24/384 | 33371/14060 999/1272 | 5 2
2014006 EsSfc | 1.13/1.13 16/16 | 46391/34319 949/1044 | 3 2
2014007 Blue LED | 1.00/1.00 64/384 | 38986/2088 966/1173 | 3 2
2014007 Red LED | 1.00/1.00 384/64 | 16080/24120 2350/1103 | 3 2
2014007 Lamp | 1.00/1.00 64/16 | 45175/58345 980/1044 | 3 2
--------------------------------------------------------------------------------------------------
Watch Circle Time Series
MOBY Kl Graph
