WED 31-JUL-2019 (212) - 23
Good Day
DATE: 01-Aug-2019 START TIME: 00:07 STOP TIME: 00:43 POSITION: 20° 48.67' N 157° 11.98' W
Quality Checking |
Engineering Info |
Forth Log
LuMid too Low
Table of Quality Checking Information
FILE: Complete
PROCESSING: Good Day
CONFIGURATION: mby26701
RAW SCANS W/ PIXELS REMOVED: VR = 23; Pixels = [775 776 777 796 797 798 803 893 894 895];
VR = 21; Pixels = [798 799 800 860 861 862 925 926 927];
VR = 19; Pixels = [842 843 844 909 930 931];
VR = 20; Pixels = [826 827 828 941 942 943];
VR = 24; Pixels = [949 948 947];
VR = 25; Pixels = [534 535 536 574 575 576 642 643 644 749 938 939 940 1011 1012 1013];
VR = 22; Pixels = [831 832 833 992 993 994];
VR = 9; Pixels = [651 650 649];
VR = 10; Pixels = [531 532 533 650 651 652 653 654 666 667 668 716 717 718];
VR = 8; Pixels = [925 924 923];
VR = 11; Pixels = [527 528 529 840 841 842 1018 1019 1020];
VR = 35; Pixels = [650 649 648];
VR = 37; Pixels = [694 695 815 816 817 873 874 875 882 883 884];
VR = 36; Pixels = [567 568 569 707 708 709 914 915 916];
VR = 34; Pixels = [534 535 536 548 549 550 677 678 679 846 847 848 958 959 960 969 970 971];
VR = 33; Pixels = [856 857 858 916 917 918 958 959 960 976 977 978];
VR = 31; Pixels = [649 650 663 932 933 943 944 945 990 991 992 994];
VR = 71; Pixels = [816 815 814];
VR = 73; Pixels = [801 800 799];
VR = 88; Pixels = [423 422 421];
VR = 87; Pixels = [443 442 441];
RAW SCANS W/ PIXELS FILLED: VR = 19; Pixels = [777 778];
VR = 22; Pixels = [803];
VR = 25; Pixels = [929];
VR = 7; Pixels = [819];
FHDS(6,:): FHDS = 'LuMid too Low';
Table of Engineering Information
| LITE | DARK |
| Int Bin Maximum | Int Bin Maximum | MUX No. No.
MOBY | Time Factor Counts | Time Factor Counts | Pos Lite Dark
File Source | (B/R) (B/R) (B/R) | (B/R) (B/R) (B/R) |
-------------------------------------------------------------------------------------------------------------
19073123 LuTop | 60.000/60.000 6/384 13929/12212 | 60.000/60.000 6/384 1066/6414 | 8 5 2
19073123 LuMid | 60.000/60.000 6/384 13356/7922 | 60.000/60.000 6/384 1083/7044 | 9 5 2
19073123 LuBot | 60.000/60.000 6/384 14907/7480 | 60.000/60.000 6/384 1072/6503 | 1 5 2
19073123 EdTop | 1.000/1.000 24/64 9208/11478 | 1.000/1.000 24/64 923/1048 | 7 5 2
19073123 EdMid | 1.500/1.500 24/64 11244/3292 | 1.500/1.500 24/64 926/1059 | 2 5 2
19073123 EdBot | 2.000/2.000 24/384 10146/3598 | 2.000/2.000 24/384 931/1230 | 10 5 2
19073123 EsSfc | 1.125/1.125 16/16 20847/17995 | 1.125/1.125 16/16 926/1035 | 5 3 2
19073123 Blue LED| 1.000/1.000 64/384 39153/1938 | 1.000/1.000 64/384 946/1146 | 12 3 2
19073123 Red LED | 1.000/1.000 384/64 18362/24881 | 1.000/1.000 384/64 1139/1047 | 13 3 2
19073123 Lamp | 1.000/0.750 64/16 45731/45311 | 1.000/0.750 64/16 948/1035 | 15 3 2
| (sec) (pixel) (AD U) | (sec) (pixel) (ADU) |
FORTH LOG FILE
No FORTH LOG file appears to exist for this MOBY file
QCHK FILE
% 19073123.mo3 Quality Check ASCII file: created on 01-Aug-2019 by MKQCHK_
OPTION14: VRpixFILL = 19; ERpixFILL = [777 778]; OPTDATESTR ='01-Aug-2019 10:06:30';
OPTION14: VRpixFILL = 22; ERpixFILL = [803]; OPTDATESTR ='01-Aug-2019 10:06:52';
OPTION2: VRpixRMD = 23; ERpixRMD = [775 776 777 796 797 798 803 893 894 895]; OPTDATESTR ='01-Aug-2019 10:07:18';
OPTION2: VRpixRMD = 21; ERpixRMD = [798 799 800 860 861 862 925 926 927]; OPTDATESTR ='01-Aug-2019 10:07:26';
OPTION14: VRpixFILL = 25; ERpixFILL = [929]; OPTDATESTR ='01-Aug-2019 10:07:31';
OPTION2: VRpixRMD = 19; ERpixRMD = [842 843 844 909 930 931]; OPTDATESTR ='01-Aug-2019 10:07:37';
OPTION2: VRpixRMD = 20; ERpixRMD = [826 827 828 941 942 943]; OPTDATESTR ='01-Aug-2019 10:07:41';
OPTION2: VRpixRMD = 24; ERpixRMD = [949 948 947]; OPTDATESTR ='01-Aug-2019 10:07:43';
OPTION2: VRpixRMD = 25; ERpixRMD = [534 535 536 574 575 576 642 643 644 749 938 939 940 1011 1012 1013]; OPTDATESTR ='01-Aug-2019 10:07:50';
OPTION2: VRpixRMD = 22; ERpixRMD = [831 832 833 992 993 994]; OPTDATESTR ='01-Aug-2019 10:07:53';
OPTION2: VRpixRMD = 9; ERpixRMD = [651 650 649]; OPTDATESTR ='01-Aug-2019 10:08:19';
OPTION2: VRpixRMD = 10; ERpixRMD = [531 532 533 650 651 652 653 654 666 667 668 716 717 718]; OPTDATESTR ='01-Aug-2019 10:08:30';
OPTION14: VRpixFILL = 7; ERpixFILL = [819]; OPTDATESTR ='01-Aug-2019 10:08:40';
OPTION2: VRpixRMD = 8; ERpixRMD = [925 924 923]; OPTDATESTR ='01-Aug-2019 10:08:49';
OPTION2: VRpixRMD = 11; ERpixRMD = [527 528 529 840 841 842 1018 1019 1020]; OPTDATESTR ='01-Aug-2019 10:08:53';
OPTION2: VRpixRMD = 35; ERpixRMD = [650 649 648]; OPTDATESTR ='01-Aug-2019 10:09:38';
OPTION2: VRpixRMD = 37; ERpixRMD = [694 695 815 816 817 873 874 875 882 883 884]; OPTDATESTR ='01-Aug-2019 10:10:44';
OPTION2: VRpixRMD = 36; ERpixRMD = [567 568 569 707 708 709 914 915 916]; OPTDATESTR ='01-Aug-2019 10:10:46';
OPTION2: VRpixRMD = 34; ERpixRMD = [534 535 536 548 549 550 677 678 679 846 847 848 958 959 960 969 970 971]; OPTDATESTR ='01-Aug-2019 10:11:09';
OPTION2: VRpixRMD = 33; ERpixRMD = [856 857 858 916 917 918 958 959 960 976 977 978]; OPTDATESTR ='01-Aug-2019 10:11:13';
OPTION2: VRpixRMD = 31; ERpixRMD = [649 650 663 932 933 943 944 945 990 991 992 994]; OPTDATESTR ='01-Aug-2019 10:11:26';
OPTION2: VRpixRMD = 71; ERpixRMD = [816 815 814]; OPTDATESTR ='01-Aug-2019 10:11:40';
OPTION2: VRpixRMD = 73; ERpixRMD = [801 800 799]; OPTDATESTR ='01-Aug-2019 10:12:12';
OPTION2: VRpixRMD = 88; ERpixRMD = [423 422 421]; OPTDATESTR ='01-Aug-2019 10:12:46';
OPTION2: VRpixRMD = 87; ERpixRMD = [443 442 441]; OPTDATESTR ='01-Aug-2019 10:12:59';
OPTION5: MOBYFNMS = '19073123.mo3'; QCHKFLAG = 1; QCHKWHAT = 1; QCHKWHO = 2; OPTDATESTR ='01-Aug-2019 10:13:59';
OPTION11: MOBYFNMS = '19073123.mo3'; QCHKFLAG = 0; QCHKWHAT = 1; QCHKWHO = 2; QCHKCODE = 0; OPTDATESTR ='01-Aug-2019 10:14:00';
OPTION13: MOBYFNMS = '19073123.mo3'; CONfile = 'mby26701'; OPTDATESTR ='14-Feb-2020 22:07:10';
OPTION7: FHDS ='LuMid too Low'; OPTDATESTR ='14-Feb-2020 22:07:11';
OPTION15: TYPEsensorBAD = 21.02; DSCSsensorBAD = 'PROBLEM'; FHDSsensorBAD = 'LuMid too Low'; OPTDATESTR ='14-Feb-2020 22:07:11';
Stephanie Flora - Moss Landing Marine Laboratories
