Campbell Time Series

The Campbell data logger controls MOBYs functional timing. It turns on the Falcon controller computer which will do a task depending upon the time it is powered up. The Campbell is also programed to power down the buoy at programmable times to make sure the system is shutdown at least once per day to return the system to a known state. The Falcon always boots from a cold state at power up. The Campbell operates based on a proprietary CRBasic programing language. Campbell analog Inputs measure Battery voltage, Campbell unit panel temperature, Case Air Temperature, Case Humidity, state of the Falcon Main Power Relay and state of the Charge Relay. Campbell has override control of the Main Power Relay and the Charge Relay. Campbell modem power is also controlled by the Campbell. The Campbell data table contains a record of the above parameters as well as important program flow flags. The voltage monitored by the Campbell is actually the voltage of the Campbell backup battery which is diode isolated from the Campbell and the Upper Battery. Due to the isolated battery supplies, this voltage is not much use in quantitatively monitoring the health of the Upper Battery. The Campbell backup battery only powers the Campbell when the Upper Battery falls below about 11.5 volts. The Campbell will operate down to a voltage of 10.5 volts at which point it will only try to switch the Charge Really to the Upper Battery to try and gain power for the controller rather than any lower batteries.

MainRlyState, 0=False=Off -1=True=On
ChargeRlyState, 0=False=Down -1=True=Up
MainRlyState is the feedback from the power relay controlling the Falcon
ChargeRlyState is the feedback from the charge relay that switches the PV power to the Upper or Lower batteries
kohms is a flooding sensor, it will go below 10K if the housing contains free water
Campbell battery = BattV
Solar panel (PhotoVoltaic cell) voltage = PVVolts


Reading for the last day of the file: 30-Sep-2020 17:08:00 to 29-Sep-2020 17:08:00 (1 day)
Measurment Mean Min Max %std
CamBattV 13.1989 12.47 14 2.88
PTemp_C 27.4521 26.14 29.5 3.71
AirTC 27.2522 25.81 29.6 4.39
RH 22.8135 22.03 23.97 2.48
kohms 15.0432 13.98 16.14 0.88
Measurment Minutes Down Minutes Up
ChargeRlyState 4.5833 19.4333
Measurment Minutes Off Minutes On
MainRlyState 19.75 4.2667

Means for the last 10 days for each day in the file (times and days from GMT time)
Day BattV PTemp_C AirTC RH kohms
20-Sep-2020 13.2889 27.2409 27.0281 22.029 15.0403
21-Sep-2020 13.216 27.3462 27.1126 22.0844 15.0325
22-Sep-2020 13.218 27.4309 27.2599 22.2094 15.0464
23-Sep-2020 13.1968 27.8189 27.5464 22.3971 15.0436
24-Sep-2020 13.1569 27.8325 27.6673 22.1593 15.0323
25-Sep-2020 13.2169 27.5951 27.421 22.1399 15.0473
26-Sep-2020 13.2104 27.632 27.4558 22.2863 15.0525
27-Sep-2020 13.2086 27.7249 27.5288 22.5269 15.0626
28-Sep-2020 13.2134 27.9337 27.8666 22.4824 15.0492
29-Sep-2020 13.1974 27.7831 27.6642 22.5754 15.0385
30-Sep-2020 13.0491 27.3912 27.126 22.7328 15.0621

Campbell Start and Stop Times for turning on (last 20 cycles) - MainRlyState = -1
On/Off Start Time Stop Time Delta Time (hours)
Off 28-Sep-2020 23:12:00 28-Sep-2020 23:46:00 0.57
On 28-Sep-2020 23:47:00 29-Sep-2020 00:49:00 1.03
Off 29-Sep-2020 00:50:00 29-Sep-2020 02:59:00 2.15
On 29-Sep-2020 03:00:00 29-Sep-2020 03:15:00 0.25
Off 29-Sep-2020 03:16:00 29-Sep-2020 03:59:00 0.72
On 29-Sep-2020 04:00:00 29-Sep-2020 04:15:00 0.25
Off 29-Sep-2020 04:16:00 29-Sep-2020 16:59:00 12.72
On 29-Sep-2020 17:00:00 29-Sep-2020 17:15:00 0.25
Off 29-Sep-2020 17:16:00 29-Sep-2020 17:59:00 0.72
On 29-Sep-2020 18:00:00 29-Sep-2020 18:15:00 0.25
Off 29-Sep-2020 18:16:00 29-Sep-2020 20:37:00 2.35
On 29-Sep-2020 20:38:00 29-Sep-2020 21:41:00 1.05
Off 29-Sep-2020 21:42:00 29-Sep-2020 22:07:00 0.42
On 29-Sep-2020 22:08:00 29-Sep-2020 23:11:00 1.05
Off 29-Sep-2020 23:12:00 29-Sep-2020 23:46:00 0.57
On 29-Sep-2020 23:47:00 30-Sep-2020 00:49:00 1.03
Off 30-Sep-2020 00:50:00 30-Sep-2020 02:59:00 2.15
On 30-Sep-2020 03:00:00 30-Sep-2020 03:15:00 0.25
Off 30-Sep-2020 03:16:00 30-Sep-2020 03:59:00 0.72
On 30-Sep-2020 04:00:00 30-Sep-2020 04:15:00 0.25
Off 30-Sep-2020 04:16:00 30-Sep-2020 16:59:00 12.72

Start and Stop Times for when Falcon switches the Charge Relay (last 20 cycles) - ChargeRlyState = -1
Up/Down Start Time Stop Time Delta Time (hours)
Up 29-Sep-2020 17:14:00 29-Sep-2020 18:09:00 0.92
Down 29-Sep-2020 18:10:00 29-Sep-2020 18:12:00 0.03
Up 29-Sep-2020 18:13:00 29-Sep-2020 20:44:00 2.52
Down 29-Sep-2020 20:45:00 29-Sep-2020 21:04:00 0.32
Up 29-Sep-2020 21:05:00 29-Sep-2020 21:39:00 0.57
Down 29-Sep-2020 21:40:00 29-Sep-2020 22:09:00 0.48
Up 29-Sep-2020 22:10:00 29-Sep-2020 22:15:00 0.08
Down 29-Sep-2020 22:16:00 29-Sep-2020 22:34:00 0.30
Up 29-Sep-2020 22:35:00 29-Sep-2020 23:08:00 0.55
Down 29-Sep-2020 23:09:00 29-Sep-2020 23:09:00 0.00
Up 29-Sep-2020 23:10:00 29-Sep-2020 23:10:00 0.00
Down 29-Sep-2020 23:11:00 29-Sep-2020 23:48:00 0.62
Up 29-Sep-2020 23:49:00 29-Sep-2020 23:54:00 0.08
Down 29-Sep-2020 23:55:00 30-Sep-2020 00:13:00 0.30
Up 30-Sep-2020 00:14:00 30-Sep-2020 00:48:00 0.57
Down 30-Sep-2020 00:49:00 30-Sep-2020 03:01:00 2.20
Up 30-Sep-2020 03:02:00 30-Sep-2020 03:09:00 0.12
Down 30-Sep-2020 03:10:00 30-Sep-2020 03:13:00 0.05
Up 30-Sep-2020 03:14:00 30-Sep-2020 04:09:00 0.92
Down 30-Sep-2020 04:10:00 30-Sep-2020 04:12:00 0.03
Up 30-Sep-2020 04:13:00 30-Sep-2020 17:08:00 12.92


Stephanie Flora - Moss Landing Marine Laboratories
