REVISION DATE: 08-Apr-2015 10:26:03
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015040720_img | Signal | 650 | 0.17 | Single Scan | -10 | 0 | F | 2015-04-07T04:35:10 | 1 | Image | 33227 | 1212.54 | 82.35 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
