REVISION DATE: 08-Apr-2015 10:26:04
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015040726_img | Signal | 600 | 0.12 | Single Scan | -10 | 0 | F | 2015-04-07T05:10:30 | 1 | Image | 31248 | 1157.24 | 25.92 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
