REVISION DATE: 08-Apr-2015 14:11:42
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015040811_img | Signal | NaN | 5 | Single Scan | -10 | 0 | F | 2015-04-08T06:19:09 | 1 | Image | 49838 | 16486.68 | 88.54 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
