REVISION DATE: 08-Apr-2015 14:11:43
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015040815_img | Signal | NaN | 9 | Single Scan | -10 | 0 | F | 2015-04-08T06:23:34 | 1 | Image | 62502 | 28284.44 | 68.15 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
