REVISION DATE: 09-Apr-2015 13:50:19
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015040913_img | Signal | NaN | 8 | Single Scan | -40 | 0 | F | 2015-04-09T06:48:18 | 1 | Image | 63578 | 13312.30 | 126.11 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
