REVISION DATE: 10-Apr-2015 10:30:46
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015041004_img | Signal | 450 | 0.4 | Single Scan | -40 | 0 | F | 2015-04-10T03:02:40 | 4 | Image | 34281 | 3829.03 | 8.68 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
