REVISION DATE: 14-Aug-2015 11:07:27
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015081309_img | Signal | 80 | 350 | 60 | Single Scan | -40 | 0 | F | 2015-08-13T03:50:09 | 4 | Image | 11711 | 4424.97 | 2.53 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
