REVISION DATE: 14-Aug-2015 11:05:19
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015081408_img | Signal | 70 | 425 | 2 | Single Scan | -40 | 0 | F | 2015-08-14T04:52:22 | 4 | Image | 18649 | 3486.09 | 5.02 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
