REVISION DATE: 16-Aug-2015 19:58:34
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| b2015081523_img | Background | 0 | 675 | 3.5 | Single Scan | -40 | 0 | F | 2015-08-15T04:41:08 | 4 | Image | 3909 | 3507.19 | 0.32 |
Figure 1
Figure 2
