REVISION DATE: 23-Aug-2015 19:20:13
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015082203_img | Signal | 90 | NaN | 10 | Single Scan | -40 | 0 | F | 2015-08-22T04:29:31 | 4 | Image | 4801 | 3638.72 | 0.85 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
