REVISION DATE: 03-Jul-2015 13:23:57
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | RAW HTML | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015070308_img | Signal | NaN | 0.05 | Single Scan | -40 | 0 | F | 2015-07-03T04:22:45 | 4 | Image | 57116 | 4578.73 | 126.44 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
