REVISION DATE: 27-Jul-2015 10:18:23
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015072409_img | Signal | NaN | 2.2 | Single Scan | -42 | 0 | F | 2015-07-24T05:28:17 | 4 | Image | 10381 | 3600.04 | 16.57 |
Figure 1
Figure 2
Figure 3
Figure 4
