REVISION DATE: 27-Jul-2015 10:39:59
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015072509_img | Signal | NaN | 2.2 | Single Scan | -40 | 0 | F | 2015-07-25T03:05:21 | 4 | Image | 11197 | 3607.41 | 18.71 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
