REVISION DATE: 27-Jul-2015 10:39:59
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | RAW HTML | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Laser Wavelength (nm) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015072515_img | Signal | NaN | 2.2 | Single Scan | -40 | 0 | F | 2015-07-25T03:12:28 | 4 | Image | 13861 | 3661.87 | 26.74 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
