REVISION DATE: 12-Apr-2016 11:20:11
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2016041203_img | Signal | NaN | NaN | 0.1 | Single Scan | -40 | 0 | F | 2016-04-12T02:59:43 | 4 | Image | 55674 | 5361.26 | 143.89 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
