REVISION DATE: 12-May-2016 14:44:15
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2016051007_img | Signal | NaN | NaN | 0.05 | Single Scan | -40 | 0 | F | 2016-05-10T06:58:11 | 4 | Image | 6951 | 3714.80 | 10.12 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
