REVISION DATE: 12-May-2016 14:42:34
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | RAW HTML | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2016051135_img | Signal | NaN | NaN | 90 | Single Scan | -40 | 0 | F | 2016-05-11T06:14:44 | 4 | Image | 28159 | 9509.60 | 57.24 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
