REVISION DATE: 19-May-2016 11:25:28
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2016051907_img | Signal | NaN | NaN | 15 | Single Scan | -40 | 0 | F | 2016-05-19T05:42:13 | 4 | Image | 13797 | 4401.94 | 34.54 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
