REVISION DATE: 26-May-2016 14:58:05
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2016052602_img | Signal | NaN | NaN | 2 | Single Scan | -40 | 0 | F | 2016-05-26T02:09:32 | 4 | Image | 41146 | 4560.19 | 97.04 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
