REVISION DATE: 15-Apr-2016 08:23:35
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2016041505_img | Signal | NaN | NaN | 0.35 | Single Scan | -40 | 0 | F | 2016-04-15T03:42:10 | 4 | Image | 46704 | 4922.72 | 121.78 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
