REVISION DATE: 09-Sep-2016 10:53:38
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2016090802_img | Signal | NaN | NaN | 0.2 | Single Scan | -20 | 0 | T | 2016-09-08T01:53:44 | 4 | Image | 1975 | 800.81 | 45.37 |
Figure 1
Figure 2
Figure 3
Figure 4
