REVISION DATE: 18-Oct-2016 11:18:07
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | RAW HTML | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2016101823_img | Signal | NaN | 500 | 1 | Single Scan | -40 | 0 | F | 2016-10-18T06:09:45 | 4 | Image | 64722 | 3529.09 | 45.18 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
