REVISION DATE: 03-Apr-2017 11:39:58
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks/bkgrd subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2017033102_img | Signal | NaN | 350 | 1.5 | Single Scan | -60 | 0 | F | 2017-03-31T03:27:47 | 4 | Image | 44397 | 4056.53 | 35.66 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
