REVISION DATE: 27-Mar-2017 13:58:12
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | RAW HTML | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2017032501_20476_img | Signal | NaN | NaN | 0.1 | Single Scan | -60 | 0 | F | 2017-03-25T03:06:21 | 4 | Image | 33003 | 27996.52 | 2.66 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
