REVISION DATE: 29-Jul-2017 08:20:00
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2017072915_img | Signal | NaN | NaN | 0.9 | Single Scan | -40 | 0 | F | 2017-07-29T07:09:50 | 4 | Image | 60975 | 5546.04 | 115.11 |
Figure 1
Figure 2
Figure 3
Figure 4
