RS_20190717_050020_raw01 - Day 1

REVISION DATE: 18-Jul-2019 19:15:19

Exerimental BS or RS data starting to put data into new Vaux setup.


Table caption: RS03 Data
Dataset# Filename / Fit# Type file creation date Total Exposure Time Tracks on Temperature Pre Amplifier Gain Matrix Max (ADU) Matrix Mean (ADU) Matrix % std
1 RS_20190717_050020_raw01 / 001 Background 17-Jul-2019 05:00:20 1.75 1 2 3 4 5 6 7 8 9 10 11 12 13 14 -40 4 3670 3503.0777 0.26424
1 RS_20190717_050020_raw01 / 002 Background 17-Jul-2019 05:00:59 1.75 1 2 3 4 5 6 7 8 9 10 11 12 13 14 -40 4 3667 3504.8567 0.26888
1 RS_20190717_050020_raw01 / 001 Lite 17-Jul-2019 05:01:14 1.75 1 2 3 4 5 6 7 8 9 10 11 12 13 14 -40 4 42865 5035.4814 101.6692
1 RS_20190717_050020_raw01 / 002 Lite 17-Jul-2019 05:01:31 1.75 1 2 3 4 5 6 7 8 9 10 11 12 13 14 -40 4 42785 5036.2589 101.5852
1 RS_20190717_050020_raw01 / 003 Lite 17-Jul-2019 05:01:45 1.75 1 2 3 4 5 6 7 8 9 10 11 12 13 14 -40 4 42823 5037.4405 101.6302
1 RS_20190717_050020_raw01 / 004 Lite 17-Jul-2019 05:02:03 1.75 1 2 3 4 5 6 7 8 9 10 11 12 13 14 -40 4 42856 5038.3113 101.6698
1 RS_20190717_050020_raw01 / 003 Background 17-Jul-2019 05:02:27 1.75 1 2 3 4 5 6 7 8 9 10 11 12 13 14 -40 4 3656 3502.2915 0.26488
1 RS_20190717_050020_raw01 / 004 Background 17-Jul-2019 05:02:41 1.75 1 2 3 4 5 6 7 8 9 10 11 12 13 14 -40 4 3653 3504.1267 0.26886

Grouped Image file: RS_20190717_N001_grouped.html
Grouped Image file: RS_20190717_N003_grouped.html
Grouped Image file: RS_20190717_N005_grouped.html
Grouped Image file: RS_20190717_N006_grouped.html
Grouped Image file: RS_20190717_N007_grouped.html
Grouped Image file: RS_20190717_N020_grouped.html
Grouped Image file: RS_20190717_N022_grouped.html


Figure 1A: Mikes Lamp monitoring log files. One shows the whole data set and one shows only the data with FITS files. black * is the number from Mikes logsheet.



Figure 2A: Mikes Lamp monitoring log files. One shows the whole data set and one shows only the data with FITS files. black * is the number from Mikes logsheet.



Graphs below are of the Nets for a dataset. A dataset is a group of dark-lite-dark files that Mike says in his logsheet are collected together. One net = darks before and after averaged then , lights averaged, then avg_lite-avg_dark and the avg_net divided by intergration time for each track.

Figure 1B: All the net data sets with a track illuminated. This shows ALL the net tracks with light on them.



Figure 2B: The net for one dataset (dark-lite-dark) for all tracks illuminated or not. This allows you to see the straylight on other tracks. The dataset number and fits files used to create this net are in the title of the figure.



pwd: E:\zflora\mldata2\mobyrefresh\characterization\Hawaii-2019-03\RS03
Date: 18-Jul-2019 19:15:19
Created from mkhtml2_(1)
