REVISION DATE: 06-Dec-2017 13:03:33
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2017120106_img | Signal | NaN | NaN | 5 | Single Scan | -40 | 0 | F | 2017-12-01T00:37:41 | 4 | Image | 47567 | 13140.93 | 78.22 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
