s2017120140_img

REVISION DATE: 06-Dec-2017 13:09:36

Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.

Table caption: Andor Ikon Camera data, NOT divided by intgration time (no darks are subtractd)
Previous HOME NEXT
Filename Type Rotaton
(deg)
Wavelength (nm)(deg) Total Exposure Time Acquisition mode Temperature Gain Baseline Clamp file creation date Pre Amplifier Gain Readout mode Matrix Max (ADU) Matrix Mean (ADU) Matrix % std
s2017120140_img Signal NaN NaN 5 Single Scan -40 0 F 2017-12-01T22:56:46 4 Image 47660 13145.32 78.20

Figure 1


Figure 2


Figure 3


Figure 4


Figure 5


Figure 6


pwd: E:\zflora\mldata\mobyrefresh\characterizations\intial\MOBY-L267\bs4cal\day04
Date: 06-Dec-2017 13:09:36
