REVISION DATE: 15-Dec-2017 13:10:41
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s20171215020_img | Signal | NaN | NaN | 20 | Single Scan | -40 | 0 | F | 2017-12-15T05:03:51 | 4 | Image | 14094 | 3882.22 | 27.66 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
