s20180213018_img

REVISION DATE: 14-Feb-2018 10:15:01

Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.

Table caption: Andor Ikon Camera data, NOT divided by intgration time (no darks are subtractd)
Previous HOME NEXT
Filename Type Rotaton
(deg)
Wavelength (nm)(deg) Total Exposure Time Acquisition mode Temperature Gain Baseline Clamp file creation date Pre Amplifier Gain Readout mode Matrix Max (ADU) Matrix Mean (ADU) Matrix % std
s20180213018_img Signal NaN NaN 50 Single Scan -60 0 F 2018-02-13T06:22:26 4 Image 40067 4047.25 9.84

Figure 1


Figure 2


Figure 3


Figure 4


pwd: E:\zflora\mldata\mobyrefresh\characterizations\intial\MOBY-L267\bs3cal\day04
Date: 14-Feb-2018 10:15:01
Created from mkhtml_(1)
