s2017040617_img

REVISION DATE: 07-Apr-2017 14:09:57

Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.

Table caption: Andor Ikon Camera data, NOT divided by intgration time (no darks are subtractd)
Previous HOME NEXT
Filename Type Rotaton
(deg)
Wavelength (nm)(deg) Total Exposure Time Acquisition mode Temperature Gain Baseline Clamp file creation date Pre Amplifier Gain Readout mode Matrix Max (ADU) Matrix Mean (ADU) Matrix % std
s2017040617_img Signal NaN NaN 5.6139 Single Scan -60 0 F 2017-04-06T22:41:02 4 Image 45128 4969.85 95.96

Figure 1


Figure 2


Figure 3


Figure 4


pwd: E:\zflora\mldata\mobyrefresh\characterizations\intial\MOBY262\bs01\day27
Date: 07-Apr-2017 14:09:57
Created from mkhtml_(1)
