REVISION DATE: 16-Oct-2017 15:28:25
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | RAW HTML | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2017101619_img | Signal | NaN | NaN | 15.9254 | Single Scan | -60 | 0 | F | 2017-10-16T00:22:52 | 4 | Image | 20699 | 4756.94 | 52.75 |
Figure 1
Figure 2
Figure 3
Figure 4
