s20180223092_img

REVISION DATE: 26-Feb-2018 12:57:39

Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.

Table caption: Andor Ikon Camera data, NOT divided by intgration time (no darks are subtractd)
Previous HOME NEXT
Filename Type Rotaton
(deg)
Wavelength (nm)(deg) Total Exposure Time Acquisition mode Temperature Gain Baseline Clamp file creation date Pre Amplifier Gain Readout mode Matrix Max (ADU) Matrix Mean (ADU) Matrix % std
s20180223092_img Signal NaN NaN 3.7466 Single Scan -60 0 F 2018-02-23T21:14:38 4 Image 40127 4795.60 97.31

Figure 1


Figure 2


Figure 3


Figure 4


pwd: E:\zflora\mldata\mobyrefresh\characterizations\intial\MOBY264\bs04\dataset_100\21hr\day16
Date: 26-Feb-2018 12:57:39
