REVISION DATE: 02-Mar-2018 14:26:23
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s20180227059_img | Signal | NaN | NaN | 28.6403 | Single Scan | -60 | 0 | F | 2018-02-27T22:50:58 | 4 | Image | 47276 | 4137.91 | 68.99 |
Figure 1
Figure 2
Figure 3
Figure 4
