s2018030127_img

REVISION DATE: 02-Mar-2018 11:39:48

Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.

Table caption: Andor Ikon Camera data, NOT divided by intgration time (no darks are subtractd)
Previous HOME NEXT
Filename Type Rotaton
(deg)
Wavelength (nm)(deg) Total Exposure Time Acquisition mode Temperature Gain Baseline Clamp file creation date Pre Amplifier Gain Readout mode Matrix Max (ADU) Matrix Mean (ADU) Matrix % std
s2018030127_img Signal NaN NaN 3.3878 Single Scan -60 0 F 2018-03-01T00:38:30 4 Image 46124 5002.00 107.66

Figure 1


Figure 2


Figure 3


Figure 4


pwd: E:\zflora\mldata\mobyrefresh\characterizations\intial\MOBY264\bs04\day29
Date: 02-Mar-2018 11:39:48
Created from mkhtml_(1)
