REVISION DATE: 01-Sep-2015 10:53:39
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Wavelength (nm)(deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015090118_img | Signal | NaN | 695 | 2.4 | Single Scan | -40 | 0 | F | 2015-09-01T01:55:47 | 4 | Image | 58000 | 3514.54 | 21.19 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
