REVISION DATE: 14-Aug-2015 11:13:14
Andor Ikon Camera data. The links below are to a page for each file. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Filename | Type | Rotation (Deg) | Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| b2015080501_img | Background | 0 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:00:28 | 4 | Image | 3698 | 3483.20 | 0.27 |
| b2015080502_img | Background | 10 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:01:55 | 4 | Image | 3711 | 3483.39 | 0.27 |
| b2015080503_img | Background | 20 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:03:04 | 4 | Image | 3700 | 3483.29 | 0.27 |
| b2015080504_img | Background | 30 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:04:11 | 4 | Image | 4682 | 3484.47 | 0.28 |
| b2015080505_img | Background | 40 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:05:11 | 4 | Image | 3682 | 3486.32 | 0.27 |
| b2015080506_img | Background | 50 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:06:13 | 4 | Image | 3680 | 3487.69 | 0.27 |
| b2015080507_img | Background | 60 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:07:40 | 4 | Image | 3708 | 3485.28 | 0.27 |
| b2015080508_img | Background | 70 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:08:44 | 4 | Image | 3689 | 3483.94 | 0.27 |
| b2015080509_img | Background | 80 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:09:51 | 4 | Image | 3704 | 3482.07 | 0.27 |
| b2015080510_img | Background | 90 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:09:51 | 4 | Image | 3704 | 3482.07 | 0.27 |
| b2015080511_img | Background | 0 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:17:25 | 4 | Image | 3718 | 3480.53 | 0.27 |
| b2015080512_img | Background | 10 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:18:21 | 4 | Image | 3693 | 3481.31 | 0.27 |
| b2015080513_img | Background | 20 | 1.9 | Single Scan | -40 | 0 | F | 2015-08-05T03:19:59 | 4 | Image | 3679 | 3482.91 | 0.27 |
| b2015080514_img | Background | 30 | 2 | Single Scan | -40 | 0 | F | 2015-08-05T03:21:01 | 4 | Image | 3731 | 3484.69 | 0.28 |
| b2015080515_img | Background | 40 | 2.3 | Single Scan | -40 | 0 | F | 2015-08-05T03:22:30 | 4 | Image | 3762 | 3490.11 | 0.29 |
| b2015080516_img | Background | 50 | 2.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:23:58 | 4 | Image | 3827 | 3499.12 | 0.30 |
| b2015080517_img | Background | 60 | 3.7 | Single Scan | -40 | 0 | F | 2015-08-05T03:25:52 | 4 | Image | 3987 | 3514.85 | 0.33 |
| b2015080518_img | Background | 70 | 5.6 | Single Scan | -40 | 0 | F | 2015-08-05T03:29:00 | 4 | Image | 4203 | 3552.62 | 0.39 |
| b2015080519_img | Background | 80 | 11.5 | Single Scan | -40 | 0 | F | 2015-08-05T03:43:40 | 4 | Image | 4997 | 3651.33 | 0.62 |
| b2015080520_img | Background | 90 | 90 | Single Scan | -40 | 0 | F | 2015-08-05T03:39:40 | 4 | Image | 15677 | 4902.34 | 3.13 |
| b2015080521_img | Background | 0 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:56:09 | 4 | Image | 3687 | 3484.30 | 0.27 |
| b2015080522_img | Background | 10 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:57:25 | 4 | Image | 3716 | 3482.68 | 0.27 |
| b2015080523_img | Background | 20 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:58:31 | 4 | Image | 3691 | 3479.99 | 0.27 |
| b2015080524_img | Background | 30 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:59:37 | 4 | Image | 3697 | 3479.53 | 0.27 |
| b2015080525_img | Background | 40 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:00:31 | 4 | Image | 3686 | 3479.78 | 0.27 |
| b2015080526_img | Background | 50 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:01:43 | 4 | Image | 3717 | 3479.45 | 0.27 |
| b2015080527_img | Background | 60 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:02:31 | 4 | Image | 3687 | 3479.49 | 0.27 |
| b2015080528_img | Background | 70 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:03:36 | 4 | Image | 3681 | 3479.14 | 0.27 |
| b2015080529_img | Background | 80 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:04:26 | 4 | Image | 3707 | 3479.25 | 0.27 |
| b2015080530_img | Background | 90 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:05:33 | 4 | Image | 3683 | 3478.32 | 0.27 |
| b2015080531_img | Background | 0 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:09:45 | 4 | Image | 3679 | 3477.80 | 0.27 |
| b2015080532_img | Background | 10 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:10:56 | 4 | Image | 3696 | 3477.97 | 0.27 |
| b2015080533_img | Background | 20 | 1.9 | Single Scan | -40 | 0 | F | 2015-08-05T04:12:12 | 4 | Image | 3691 | 3481.64 | 0.27 |
| b2015080534_img | Background | 30 | 2.1 | Single Scan | -40 | 0 | F | 2015-08-05T04:13:40 | 4 | Image | 4308 | 3488.20 | 0.28 |
| b2015080535_img | Background | 40 | 2.4 | Single Scan | -40 | 0 | F | 2015-08-05T04:14:56 | 4 | Image | 3771 | 3494.25 | 0.28 |
| b2015080536_img | Background | 50 | 2.9 | Single Scan | -40 | 0 | F | 2015-08-05T04:16:22 | 4 | Image | 3842 | 3498.44 | 0.30 |
| b2015080537_img | Background | 60 | 3.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:17:43 | 4 | Image | 3950 | 3513.38 | 0.33 |
| b2015080538_img | Background | 70 | 5.7 | Single Scan | -40 | 0 | F | 2015-08-05T04:19:02 | 4 | Image | 4187 | 3545.98 | 0.40 |
| b2015080539_img | Background | 80 | 11.6 | Single Scan | -40 | 0 | F | 2015-08-05T04:20:29 | 4 | Image | 5055 | 3643.54 | 0.63 |
| b2015080540_img | Background | 90 | 90 | Single Scan | -40 | 0 | F | 2015-08-05T04:23:32 | 4 | Image | 15815 | 4902.84 | 3.13 |
| s2015080501_img | Signal | 0 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T02:59:48 | 4 | Image | 52563 | 4564.30 | 105.66 |
| s2015080502_img | Signal | 10 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:01:34 | 4 | Image | 51906 | 4549.96 | 104.69 |
| s2015080503_img | Signal | 20 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:02:42 | 4 | Image | 49802 | 4500.44 | 100.95 |
| s2015080504_img | Signal | 30 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:03:50 | 4 | Image | 45883 | 4413.33 | 94.08 |
| s2015080505_img | Signal | 40 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:04:50 | 4 | Image | 40315 | 4298.99 | 84.46 |
| s2015080506_img | Signal | 50 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:05:52 | 4 | Image | 34020 | 4162.64 | 72.46 |
| s2015080507_img | Signal | 60 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:07:15 | 4 | Image | 27058 | 4001.87 | 57.63 |
| s2015080508_img | Signal | 70 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:08:19 | 4 | Image | 19126 | 3827.71 | 40.02 |
| s2015080509_img | Signal | 80 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:09:28 | 4 | Image | 11012 | 3646.53 | 20.12 |
| s2015080510_img | Signal | 90 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:10:37 | 4 | Image | 4398 | 3500.77 | 2.43 |
| s2015080511_img | Signal | 0 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:16:23 | 4 | Image | 52872 | 4564.99 | 105.89 |
| s2015080512_img | Signal | 10 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:17:54 | 4 | Image | 51883 | 4552.04 | 104.89 |
| s2015080513_img | Signal | 20 | 1.9 | Single Scan | -40 | 0 | F | 2015-08-05T03:19:29 | 4 | Image | 52294 | 4559.75 | 105.32 |
| s2015080514_img | Signal | 30 | 2 | Single Scan | -40 | 0 | F | 2015-08-05T03:20:38 | 4 | Image | 50480 | 4523.41 | 102.46 |
| s2015080515_img | Signal | 40 | 2.3 | Single Scan | -40 | 0 | F | 2015-08-05T03:22:04 | 4 | Image | 51140 | 4533.80 | 102.66 |
| s2015080516_img | Signal | 50 | 2.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:23:34 | 4 | Image | 51066 | 4544.90 | 102.70 |
| s2015080517_img | Signal | 60 | 3.7 | Single Scan | -40 | 0 | F | 2015-08-05T03:25:24 | 4 | Image | 51292 | 4565.16 | 102.68 |
| s2015080518_img | Signal | 70 | 5.6 | Single Scan | -40 | 0 | F | 2015-08-05T03:28:29 | 4 | Image | 51234 | 4599.74 | 101.64 |
| s2015080519_img | Signal | 80 | 11.5 | Single Scan | -40 | 0 | F | 2015-08-05T03:31:57 | 4 | Image | 50655 | 4673.46 | 98.29 |
| s2015080520_img | Signal | 90 | 90 | Single Scan | -40 | 0 | F | 2015-08-05T03:37:31 | 4 | Image | 47813 | 5823.09 | 71.31 |
| s2015080521_img | Signal | 0 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:55:15 | 4 | Image | 51776 | 4584.84 | 106.15 |
| s2015080522_img | Signal | 10 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:57:04 | 4 | Image | 51457 | 4571.95 | 105.34 |
| s2015080523_img | Signal | 20 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:58:03 | 4 | Image | 48920 | 4518.57 | 101.60 |
| s2015080524_img | Signal | 30 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T03:59:08 | 4 | Image | 45309 | 4429.53 | 94.83 |
| s2015080525_img | Signal | 40 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:00:10 | 4 | Image | 39816 | 4308.32 | 85.09 |
| s2015080526_img | Signal | 50 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:01:20 | 4 | Image | 33529 | 4165.19 | 72.83 |
| s2015080527_img | Signal | 60 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:02:11 | 4 | Image | 26513 | 4003.89 | 57.98 |
| s2015080528_img | Signal | 70 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:03:16 | 4 | Image | 18781 | 3825.66 | 40.11 |
| s2015080529_img | Signal | 80 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:04:08 | 4 | Image | 10820 | 3644.48 | 20.09 |
| s2015080530_img | Signal | 90 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:05:00 | 4 | Image | 4425 | 3498.97 | 2.51 |
| s2015080531_img | Signal | 0 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:09:17 | 4 | Image | 51884 | 4580.75 | 106.49 |
| s2015080532_img | Signal | 10 | 1.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:10:35 | 4 | Image | 51248 | 4570.60 | 105.77 |
| s2015080533_img | Signal | 20 | 1.9 | Single Scan | -40 | 0 | F | 2015-08-05T04:11:45 | 4 | Image | 51411 | 4578.55 | 106.02 |
| s2015080534_img | Signal | 30 | 2.1 | Single Scan | -40 | 0 | F | 2015-08-05T04:13:15 | 4 | Image | 52484 | 4595.43 | 106.60 |
| s2015080535_img | Signal | 40 | 2.4 | Single Scan | -40 | 0 | F | 2015-08-05T04:14:31 | 4 | Image | 52010 | 4602.32 | 106.43 |
| s2015080536_img | Signal | 50 | 2.9 | Single Scan | -40 | 0 | F | 2015-08-05T04:15:58 | 4 | Image | 51979 | 4600.59 | 106.00 |
| s2015080537_img | Signal | 60 | 3.8 | Single Scan | -40 | 0 | F | 2015-08-05T04:17:14 | 4 | Image | 51816 | 4616.32 | 105.88 |
| s2015080538_img | Signal | 70 | 5.7 | Single Scan | -40 | 0 | F | 2015-08-05T04:18:37 | 4 | Image | 52117 | 4635.51 | 104.32 |
| s2015080539_img | Signal | 80 | 11.6 | Single Scan | -40 | 0 | F | 2015-08-05T04:19:54 | 4 | Image | 50282 | 4695.77 | 99.62 |
| s2015080540_img | Signal | 90 | 90 | Single Scan | -40 | 0 | F | 2015-08-05T04:21:28 | 4 | Image | 46245 | 5818.70 | 70.50 |
