REVISION DATE: 14-Aug-2015 10:15:17
Andor Ikon Camera data. None of the data had been divided by integration time. Some of the graphs do have the darks subtracted.
| Previous | HOME | NEXT | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Filename | Type | Rotaton (deg) |
Total Exposure Time | Acquisition mode | Temperature | Gain | Baseline Clamp | file creation date | Pre Amplifier Gain | Readout mode | Matrix Max (ADU) | Matrix Mean (ADU) | Matrix % std |
| s2015080534_img | Signal | 30 | 2.1 | Single Scan | -40 | 0 | F | 2015-08-05T04:13:15 | 4 | Image | 52484 | 4595.43 | 106.60 |
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
