MOBY265 BS03 in-water HDF data sets.


Table caption: MOBY265 BS03 in-water HDF data sets.
Previous HOME NEXT
Filename Type Total Exposure Time Temperature Data date Pre Amplifier Gain Matrix Max (ADU) Matrix Mean (ADU) Matrix % std
20180626_210047 light003 4.1437 NaN - 0 40077 1996.70 298.83


Figure 1: Top down surface of the data. Colorbar is in ADU.



Figure 2: Track means for the 14 graphs. Units are ADU/pix because it is a track mean. Illuminated tracks have a ** in the legend.



Figure 3: Semilogty version of the track means for the 14 graphs. Units are ADU/pix because it is a track mean. Illuminated tracks have a ** in the legend.



Figure 4: Just the illuminated tracks



Figure 5: The illuminated no illumiated. This show the cross track stray lgiht in ADU/pix units



Figure 6: Cross track plots showing the data at different pixels and the track definitions



Figure 7: Surface plot with the illuminated tracks removed so you can see the cross track stray light.



pwd: E:\zflora\mldata2\mobyrefresh\testing\hdf\moby265\hdf\bs03
Date: 18-Mar-2019 09:40:27
Created from prchdf5_(2)
cd E:\zflora\mldata2\mobyrefresh\testing\hdf\moby265\hdf\bs03\prchdf5_(2)
